Industrial boilers can be divided into steam boilers and hot water boilers

Steam boilers convert heat energy into steam by burning fuel, mainly in industrial industries, such as food industry, petrochemical industry, washing and ironing industry, packaging machinery industry, biological chemical industry, food machinery industry, etc. Industrial boilers that provide hot water are called hot water boilers and are mainly used for domestic and industrial heating. Whether it's a steam boiler or a hot water boiler they can all be expressed in terms of the amount of heat, the heating capacity of the boiler. Boiler heat supply quantity is the direct standard of boiler capacity evaluation.

Ton per hour

Also called the capacity of the boiler, boiler thermal power, and the size of the boiler output, etc., it refers to the boiler under certain pressure and temperature of steam per hour.

Usually we say 1 tons of boiler is not to say that the physical weight of the boiler is a ton, but this one is 1 ton per hour of steam boiler.

MW

In the boiler industry is usually used to show the hot water boiler in a certain pressure and a certain temperature under the output of heat per hour, that is, we often say boiler output.

0.7MW hot water boiler outputs heat equivalent to 1 ton of steam per hour.

BHP

A BHP is generally defined as the energy required producing 34.5 pounds (15.65 kg) of steam per hour at a pressure of 0 psig (0 bars) and 212 ° F (100 ° C).

Conversion relation of heating quantity of industrial boiler

Steam ton (T /h), megawatt (MW), boiler horsepower (Bhp), kilocalories /h, are units that describe boiler capacity (boiler power, boiler heat) and have equivalent or conversion relations with each other.

1t/h≈60*10⁴Kcal/h≈0.7MW，1t/h=0.72MW=720KW≈71.3Bhp，1MW=10⁶W，1KW=1000W

We provide the mainstream industrial boilers on the market, such as oil/gas boilers, biomass boilers, circulating fluidized bed boilers, thermal oil boilers and so on. ZOZEN has 1500000 square meters of production plant, more than 80% of the automated production and 59 patents, our strength can provide you with high quality products. If you are interested in our boilers and company welcome to contact us.
